Analog Devices ADV7610 Hardware User's Manual page 22

UG-438
Video ID Codes
(861 Specification) Formats
Not applicable SVGA 800 × 600p @ 56
Not applicable SVGA 800 × 600p @ 60
Not applicable SVGA 800 × 600p @ 72
Not applicable SVGA 800 × 600p @ 75
Not applicable SVGA 800 × 600p @ 85
Not applicable SXGA 1280 × 1024p @ 60
Not applicable SXGA 1280 × 1024p @ 75
Not applicable VGA 640 × 480p @ 60
Not applicable VGA 640 × 480p @ 72
Not applicable VGA 640 × 480p @ 75
Not applicable VGA 640 × 480p @ 85
Not applicable VGA 1024 × 768p @ 60
Not applicable VGA 1024 × 768p @ 70
Not applicable VGA 1024 × 768p @ 75
Not applicable VGA 1024 × 768p @ 85
Recommended Settings
Pixel if Free Run Used and
Repetition DIS_AUTO_PARAM_BUFF = 0
0 PRIM_MODE = 0x6
VID_STD = 0x0
0 PRIM_MODE = 0x6
VID_STD = 0x0
0 PRIM_MODE = 0x6
VID_STD = 0x0
0 PRIM_MODE = 0x6
VID_STD = 0x0
0 PRIM_MODE = 0x6
VID_STD = 0x0
0 PRIM_MODE = 0x6
VID_STD = 0x0
0 PRIM_MODE = 0x6
VID_STD = 0x0
0 PRIM_MODE = 0x6
VID_STD = 0x0
0 PRIM_MODE = 0x6
VID_STD = 0x0
0 PRIM_MODE = 0x6
VID_STD = 0x0
0 PRIM_MODE = 0x6
VID_STD = 0x0
0 PRIM_MODE = 0x6
VID_STD = 0x0
0 PRIM_MODE = 0x6
VID_STD = 0x0
0 PRIM_MODE = 0x6
VID_STD = 0x0
0 PRIM_MODE = 0x6
VID_STD = 0x0
Rev. 0 | Page 22 of 184
Hardware User Guide
Recommended Settings
if Free Run Not Used
or Free Run Used and
DIS_AUTO_PARAM_BUFF = 1
PRIM_MODE = 0x6
VID_STD = 0x0
PRIM_MODE = 0x6
VID_STD = 0x1
PRIM_MODE = 0x6
VID_STD = 0x2
PRIM_MODE = 0x6
VID_STD = 0x3
PRIM_MODE = 0x6
VID_STD = 0x04
PRIM_MODE = 0x6
VID_STD = 0x05
PRIM_MODE = 0x6
VID_STD = 0x06
PRIM_MODE = 0x6
VID_STD = 0x08
PRIM_MODE = 0x6
VID_STD = 0x09
PRIM_MODE = 0x6
VID_STD = 0x0A
PRIM_MODE = 0x6
VID_STD = 0x0B
PRIM_MODE = 0x6
VID_STD = 0x0C
PRIM_MODE = 0x6
VID_STD = 0x0D
PRIM_MODE = 0x6
VID_STD = 0x0E
PRIM_MODE = 0x6
VID_STD = 0x0F
