UG-438
•
DE_REGEN_LCK_RAW
•
VIDEO_3D_RAW
•
RI_EXPIRED_A_RAW
The following raw bits are all related to HDMI operation and are based on edge sensitive events; it is, therefore, necessary to clear these
bits using the corresponding clear bit.
•
NEW_ISRC2_PCKT_RAW
•
NEW_ISRC1_PCKT_RAW
•
NEW_ACP_PCKT_RAW
•
NEW_VS_INFO_RAW
•
NEW_MS_INFO_RAW
•
NEW_SPD_INFO_RAW
•
NEW_AUDIO_INFO_RAW
•
NEW_AVI_INFO_RAW
•
NEW_GAMUT_MDATA_RAW
•
FIFO_NEAR_OVFL_RAW
•
FIFO_NEAR_UFLO_RAW
•
FIFO_UNDERFLO_RAW
•
FIFO_OVERFLO_RAW
•
CTS_PASS_THRSH_RAW
•
CHANGE_N_RAW
•
PACKET_ERROR_RAW
•
AUDIO_PCKT_ERR_RAW
•
DEEP_COLOR_CHNG_RAW
•
VCLK_CHNG_RAW
•
AUDIO_MODE_CHNG_RAW
•
PARITY_ERROR_RAW
•
NEW_SAMP_RT_RAW
•
AUDIO_FLT_LINE_RAW
•
NEW_TMDS_FRQ_RAW
•
MS_INF_CKS_ERR_RAW
•
SPD_INF_CKS_ERR_RAW
•
AUD_INF_CKS_ERR_RAW
•
AVI_INF_CKS_ERR_RAW
•
AKSV_UPDATE_A_RAW
•
VS_INF_CKS_ERR_RAW

ADDITIONAL EXPLANATIONS

STDI_DATA_VALID_RAW
STDI_DATA_VALID_RAW is programmable as either an edge sensitive bit or a level sensitive bit using the following control. Note that
this control also configures whether an interrupt is generated only on the rising edge of STDI_DATA_VALID_RAW or on both edges.
STDI_DATA_VALID_EDGE_SEL, IO, Address 0x41[4]
A control to configure the functionality of the STDI_DATA_VALID interrupt. The interrupt can be generated for the case when STDI
changes to an STDI valid state. Alternatively, it can be generated to indicate a change in STDI_VALID status.
Function
STDI_DATA_VALID_EDGE_SEL
0
1 (default)
Description
Generate interrupt for a low to high change in STDI_VALID status
Generate interrupt for a low to high or a high to low change in STDI_VALID status
Rev. 0 | Page 160 of 184
