Analog Devices ADV7610 Hardware User's Manual page 19

Hardware User Guide
PRIM_MODE[3:0]
Code Description
0101 HDMI-COMP
(Component video)
0110 HDMI-GR
(Graphics)
0111 Reserved
1000 Reserved
1001 Reserved
Processor Code
CP 000000
CP 000001
CP 000010
CP 000011
000100
000101
000110
000111
001000
001001
CP 001010
CP 001011
CP 001100
CP 001101
001110
001111
010000
010001
010010
CP 010011
CP 010100
CP 010101
CP 010110
CP 010111
011000
CP 011001
CP 011010
CP 011011
CP 011100
CP 011101
CP 011110
CP 011111
CP 000000
CP 000001
CP 000010
CP 000011
CP 000100
CP 000101
CP 000110
000111
CP 001000
CP 001001
CP 001010
CP 001011
CP 001100
CP 001101
CP 001110
CP 001111
01xxxx
xxxxxx
xxxxxx
xxxxxx
Rev. 0 | Page 19 of 184
VID_STD[5:0]
Input Video Output Resolution
SD 1×1 525i 720 × 480
SD 1×1 625i 720 × 576
SD 2×1 525i 720 × 480
SD 2×1 625i 720 × 576
Reserved Reserved
Reserved Reserved
Reserved Reserved
Reserved Reserved
Reserved Reserved
Reserved Reserved
PR 1×1 525p 720 × 480
PR 1×1 625p 720 × 576
PR 2×1 525p 720 × 480
PR 2×1 625p 720 × 576
Reserved Reserved
Reserved Reserved
Reserved Reserved
Reserved Reserved
Reserved Reserved
HD 1×1 1280 × 720
HD 1×1 1920 × 1080
HD 1×1 1920 × 1035
HD 1×1 1920 × 1080
HD 1×1 1920 × 1152
Reserved Reserved
HD 2×1 720p 1280 × 720
HD 2×1 1125 1920 × 1080
HD 2×1 1125 1920 × 1035
HD 2×1 1250 1920 × 1080
HD 2×1 1250 1920 × 1152
HD 1×1 1920 × 1080
HD 1×1 1920 × 1080
SVGA 800 × 600 @ 56
SVGA 800 × 600 @ 60
SVGA 800 × 600 @ 72
SVGA 800 × 600 @ 75
SVGA 800 × 600 @ 85
SXGA 1280 × 1024 @ 60
SXGA 1280 × 1024 @ 75
Reserved Reserved
VGA 640 × 480 @ 60
VGA 640 × 480 @ 72
VGA 640 × 480 @ 75
VGA 640 × 480 @ 85
XGA 1024 × 768 @ 60
XGA 1024 × 768 @ 70
XGA 1024 × 768 @ 75
XGA 1024 × 768 @ 85
Reserved
Reserved Reserved
Reserved Reserved
Reserved Reserved
UG-438
Comment
HDMI receiver support
HDMI receiver support
