Analog Devices ADV7610 Hardware User's Manual page 25

Hardware User Guide
LLC_DLL_PHASE[4:0], IO, Address 0x19[4:0]
A control to adjust LLC DLL phase in increments of 1/32 of a clock period.
Function
LLC_DLL_PHASE[4:0]
00000 (default)
xxxxx
DLL Settings for 656, 8-/10-/12-Bit Modes
The following table shows the settings that must be used to enable 8-/10-/12-bit, 656 output.
Address
IO Map Address 0x19[7]
IO Map Address 0x33[6]
IO Map Address 0x19[6]
Description
Default
Sets one of 32 phases of DLL to vary LLC CLK
Setting
1
1
1
Rev. 0 | Page 25 of 184
Description
Enables LLC DLL
Muxes the DLL output on LLC output
Doubles the clock
UG-438
