1

Grounding Point

The power injector module automatically adjusts to any AC voltage between
100-240 volts at 50 or 60 Hz. No voltage range settings are required.
The power injector module is designed for indoor use only. Never mount
Warning:
the power injector outside with the wireless bridge unit.
Grounding Point
Even though the wireless bridge includes its own built-in lightning protection, it is
important that the unit is properly connected to ground. A grounding screw is
provided for attaching a ground wire to the unit.

Water Tight Test Point

Do no remove or loosen this screw. Doing so could lead to damage of the
Caution:
unit.

Wall- and Pole-Mounting Bracket Kit

The wireless bridge includes a bracket kit that can be used to mount the bridge to a
wall, pole, radio mast, or part of a tower structure.
1-7
