Introduction
The 11a and 11b/g LEDs operate in two display modes, which are configurable
through the management interface. The RSSI mode is for aligning antennas in a
bridge link. The AP mode is for indicating data traffic rates.
The following table describes the wireless status LEDs in AP mode.
LED
11a
(three LEDs)
11b/g
(three LEDs)
The following table describes the wireless status LEDs in RSSI mode.
LED
11a
(three LEDs)
11b/g
(three LEDs)
1-4
Status Description
Off No signal detected or the 802.11a radio is disabled.
Slow Flashing Green The 802.11a radio is enabled with a low level of network
activity.
Fast Flashing Green Indicates a medium level of network activity.
On Green Indicates a high level of network activity.
Off No signal detected or the 802.11b/g radio is disabled.
Slow Flashing Green The 802.11b/g radio is enabled with a low level of network
activity.
Fast Flashing Green Indicates a medium level of network activity.
On Green Indicates a high level of network activity.
Status Description
Off No signal detected or the 802.11a radio is disabled.
Slow Flashing Green The 802.11a radio is enabled with a low level signal.
Fast Flashing Green Indicates a medium level signal.
On Green Indicates a high level signal.
Off No signal detected or the 802.11b/g radio is disabled.
Slow Flashing Green The 802.11b/g radio is enabled with a low level signal.
Fast Flashing Green Indicates a medium level signal.
On Green Indicates a high level signal.
