Mix-Points

DSP Configurator contains four mix matrices that connect all inputs and outputs. The mix

matrices set post-processing mix levels.

Each input is connected to a mix-point for the signal to be routed to an output. In general,

mix levels are set relative to each other, achieving a blend of input signals at an optimal

output level, close to, but not exceeding 0 dBFS at the output.

NOTE: In order for mix-points to appear in the workspace, the input group sending

signal to the mix-point must be expanded and the input channel must be visible.

Figure 50.

DSP Configurator Mix Matrices

NetPA Ultra Series • DSP Configurator Software
