Figure 60.
8. Set the Amp Out attenuator(s) to 0 dB (see figure 62). The attenuation value can be
adjusted by either dragging the fader (
manually entering the desired value.
1 1 1
2 2 2
3 3 3
Figure 61.
9. Click OK (

Amplifier Outputs

The NetPA U 1004, features four discrete processing paths to the amplifier outputs, while
the NetPA U 1002 features two processing paths to the amplifier outputs. All audio inputs
can be routed to an amplifier output via discrete amplifier output mix-points.
Figure 62.
Figure 63.
Amplifier Outputs Block
Amp Out Dialog Box
) to apply the change and close the dialog box.
3
Amplifier Output Panel for the NetPA U 1004
Amplifier Output Panel for the NetPA U 1002
NetPA Ultra Series • DSP Configurator Software
), or clicking in the display box (
1
), and
2
