Methods for Marking Items

Marked items are highlighted in green (see figure 68). There are four ways to mark items in
DSP Configurator:
• Mark All — Press <Ctrl+A> on the keyboard to mark all items in the main workspace.
Mark Group — Click and drag the cursor to create a box around a group of items to
•
mark them.
Click and drag the cursor while holding the
group of items to mark them while keeping previous group marked.
Mark Series — Click the first item in the series to mark it, then press <Shift+Click>
•
on the final item in the series. All items between the first and last items are marked.
Mark Multiple Individual – Click the first item to mark it and press <Ctrl+Click> to
•
mark additional items anywhere in the main workspace.
Figure 68.

Configuring Presets

1. Create a configuration to be saved as a preset (see
page 28).
2. Mark the items to be included in the preset.
3. Select Tools > Presets > Save Preset.
From the Save a Preset dialog box, enter the preset number (1 through 8) in the
4.
Preset Number field (see figure 69,
assigned read unassigned. Enter a name into the Preset Name field (
maximum).
5. Click OK (
Figure 69.
NOTE: When a configuration file is pushed to a NetPA Ultra Series amplifier, presets
contained within that file are available for recall from DSP Configurator or SIS
commands.
6. The preset is saved and is available from the Presets
drop-down list at the top of the main workspace.
Marked Items Highlighted in Green
) to save the preset.
3
1
2
3
Save a Preset Dialog Box
Shift key to create box around another
< >
DSP Configurator Software
). Preset slots that do not already have a preset
1
NetPA Ultra Series • Configuration Tools
on
), 12 character
2
