Operation

This section describes the operation of the NetPA Ultra Series Amplifiers. Topics include:
•
•
•

Front Panel Features

1
1
Power/Standby Indicator
1
Figure 12.
NOTE: The front panels of all models in the NetPA Ultra Series function identically.
1
Front Panel Features
Rear Panel Features
Operation
2 3
OVER
TEMP
1 2 3 4
LIMITER/PROTECT
SIGNAL
2 3
OVER
TEMP
1 2
LIMITER/PROTECT
SIGNAL
NetPA Ultra Series Front Panel
Power/Standby LED — A single LED that lights green when the unit is on and active,
and lights amber when:
The unit is powering up and booting.
•
• The unit is in standby mode, which turns off all outputs from the amplifier although
the amplifier still receives power.
DC voltage is detected (see
•
This LED unit flashes amber when an Identify Device request is sent to the unit
•
via Dante Controller, and the Link Indicator LED located on the rear panel blinks
green. Once the cycle has been completed, the LEDs return to normal.
NOTE: Power indicator LED may light amber for a short time after the removal
of AC power. This is normal.
• Standby modes
• Hardware Reset Modes
Over Temp Indicator
2
Troubleshooting on page 101)
