AT Port

The NetPA U 1004 supports four AT inputs, as well as four AT outputs (which are shared
with the analog line outputs), while the NetPA U 1002 only supports 2 AT inputs and 2 AT
outputs (these are not shared with the analog line outputs). Audio coming in from the
mic/line inputs can be placed onto the Dante network, and the AT outputs can be
received by any other device as long as it is using the Dante protocol. The port supports
bi-directional channels of 24 bit/48 kHz digital audio.
NOTE: The AT port can be set to 44.1 kHz, 48 kHz, 88.2 kHz, or 96 kHz, however the
The AT port allows latency to be set per device at either 1.0 ms, 2.0 ms, or 5.0 ms.
Dante Controller provides control and configuration to the entries listed below. However,
Dante Controller is not limited to the entries.
•
•
•
•
•
•
NOTES:

Standby modes

The amplifier may be placed into 3 standby modes through SIS, DSP Configurator or
a control system. The amplifier may also be forced into standby through the rear panel
contact closure.
To change the Standby settings via DSP Configurator:
Navigate to the Tools menu and select Configure Standby Settings, then make your
selection to change the settings (see
Standby modes
•
•
•
signal going through the DSP is converted to and processed at 48 kHz.
Dante channel routing
Dante channel naming
Dante reboot
Device naming
Setting network master clock
Get network and device Dante status
• For applications where the line and Dante outputs may be used independently
during long periods of no amplifier activity, such as when the unit is being used as
both an amplifier and off/on-ramp to the Dante network, the auto-standby timer
must be disabled and the amp must not be forced into standby mode.
• On NetPA U 1004 models, selecting 88.2 kHz or 96 kHz sample rates disables
the transmit channels.
Mode 0 = Disable Auto-Standby Timer
Mode 1 = Enable Auto-Standby Timer
Mode 2 = Force Standby mode
• Set DHCP mode and device IP address
• Setting sample rate to one of the
following frequencies:
44.1 kHz
•
• 48 kHz
figure 19 on the next page).
NetPA Ultra Series • Operation
• 88.2 kHz
• 96 kHz
