Edit
The Edit menu offers the standard Windows Edit Menu options such as Cut, Copy, and
Paste.
View
• Meter Bridge — Opens a meter bridge to view input and output activity. The meter
bridge is a floating window that allows the use of DSP Configurator while simultaneously
monitoring input and output activity.
NOTE:
The meter bridge is only available in Live mode with a TCP/IP connection.
• Re-enable All Dialogs — This option re-enables all dialog boxes to no longer appear
based on user selection (certain dialog boxes appear as user-defeatable by selecting a
checkbox that reads Do Not Show This Dialog Again).
Group Controls — Opens the Group Controls dialog box to access existing group
•
controls and add new groups.
Show All Channels — Individual channels can be hidden by user selection. This
•
provides options for the user to select which input and output groups are visible in the
main workspace.
Tools
• Presets — Contains a submenu to mark and clear elements in the main workspace as
well as an option to save marked elements to a preset (see
Configure Groups — Opens the Configure Groups dialog box to create, edit, and
•
delete Gain and Mute groups (see
• Configure Standby Settings — Opens a submenu to disable or enable the auto-
standby timer or force standby mode.
Connect/Disconnect from Device — When in Emulate mode, this reads as
•
Connect to Device and opens the Connect to Device
Disconnect from Device
from Device and returns software to Emulate mode.
Device Manager — Opens the Device Manager dialog box (see
•
page 68)
.
• Issue RESET Command — Clears the amplifier of all processors and other
configuration settings. This command does not reset general settings such as IP
address.
Firmware Loader — Opens the Firmware Loader application, if it is installed (see
•
Firmware Loader
on page 70). Visit
• Organize Building Blocks — Opens the Organize Building Blocks dialog box (see
Organize Building Blocks
Device Settings — Opens the Device Settings dialog box to edit date and time, IP
•
address, DHCP status, and other settings (see
Options — Opens the Options dialog box to configure DSP Configurator appearance,
•
default settings, DSP value defaults, and so on (see
Network Audio Control — Opens the Dante Controller application by Audinate for
•
routing audio over a Dante network (see
Configuring Groups
on page 70). When in Live mode, this reads Disconnect
www.extron.com
on page 71)
.
Device Settings
Options
Dante Controller
NetPA Ultra Series • DSP Configurator Software
Presets
on page 63).
on page 66)
.
Connect/
dialog box (see
Device Manager
to download the software.
on page 72)
.
on page 74)
.
on page 75).
on
