3.9.4 HOT ROLLER AND FUSING LAMP

[A]
1. Remove the fusing unit. (
2. Remove: ( 3.9.3)
• Fusing upper cover.
• Pressure springs.
• Hot roller stripper bracket.
3. Remove the fusing lamps (
NOTE: Do not touch the surface of the fusing lamp with bare hands.
4. Replace the hot roller [B] (C-rings x2, Gear x1, Bushings x2).
Reinstallation
• When you reattach the C-rings, the flat sides must face the bearing/roller. (The
little hooks [C] must face away from the bearing/roller).
[C]
3.9.1)
x4) and hot roller assembly [A].
3-33
B205R938.WMF
[B]
FUSING/EXIT
[C]
B205R939.WMF
