Ricoh R-C4 Service Manual page 255

21 July 2006
5858* Debug Save When
These SPs select the content of the debugging information to be saved to the
destination selected by SP5857 002.
SP58583 stores one SC specified by number. Refer to Section 4 for a list of
SC error codes.
58581* Engine SC Error (0:OFF 1:ON)
58582* Controller SC Error (0:OFF
1:ON)
58583* Any SC Error (0:OFF 1:ON)
58584* Jam (0:OFF 1:ON)
5859 Debug Log Save Function
5859 1 Key 1
5859 2 Key 2
5859 3 Key 3
5859 4 Key 4
5859 5 Key 5
5859 6 Key 6
5859 7 Key 7
5859 8 Key 8
5859 9 Key 9
5859 10 Key 10
5860 SMTP/POP3/IMAP4
5860 1 SMTP Server Name
Allows you to specify the name of the SMTP server. Enter either the host name or
the IP address. If you enter the host name, you must also specify the name of the
DNS server.
5860 2 SMTP Server Port Number
This SP sets the number of the SMTP server port.
[1~65535/1]
5860 3 SMTP Certification
This setting switches SMTP certification on and off for mail sending.
0: Off
1: On
5860 4 SMTP Certification User Name
Allows you to set the user name to be used for SMTP certification. This user
name is used only when the user name for SMTP certification has not been
selected with the software application. The user name includes the "realmID"
string.
5860 5 SMTP Certification Password
Allows you to set the password to be used for SMTP certification. The length of
the password is limited to 128 alphanumeric characters.
5860 6 SMTP Certification Encryption
This setting determines whether the password for SMTP certification is encrypted.
0: Automatic
1: No encryption done
2: Encryption done
Stores SC codes generated by copier
engine errors.
Stores SC codes generated by GW
controller errors.
[0~65535 / 0 / 1]
Stores jam errors.
These SPs allow you to set up to 10 keys for log files for
functions that use common memory on the controller board.
[-9999999~9999999/1]
5-67
SERVICE PROGRAM MODE
