Ricoh R-C4 Service Manual page 309

21 July 2006
Number Bit
7 Not Used
6 Not Used
5 Not Used
Group 4 (Only 4 Not Used
1000 Fin.)
3 Upper Tray Paper Limit Sensor
2 Not Used
1 Not Used
0 Not Used
For 500-sheet Finisher
Number Bit
7 Stack Near-limit Sensor
6 Tray Upper Limit Sensor
5 Lever Sensor
4 Stack Height Sensor
1
3 Top Cover Sensor
2 Jogger HP Sensor
1 Exit Sensor
0 Entrance Sensor
7 Not Used
6 Not Used
5 Not Used
4 Staple Unit Lock
2
3 Staple Cartridge Sensor
2 Staple End Sensor
1 Staple Hammer HP Sensor
0 Staple Unit Cover Switch
Description
Description
5-121
SERVICE PROGRAM MODE
Reading
0
Activated Deactivated
Reading
0
Activated Deactivated
Activated Deactivated
Activated Deactivated
Activated Deactivated
Closed Opened
Activated Deactivated
Activated Deactivated
Activated Deactivated
Locked Not Locked
Activated Deactivated
Activated Deactivated
Activated Deactivated
Closed Opened
1
1
