COPIER INSTALLATION
[A]
4. If the optional bridge unit will not be installed, swing the sensor feeler [A] out.
5. Install the optional ARDF or the optional platen cover (see "ARDF Installation"
( 1.5) or "Platen Cover Installation" ( 1.14)).
6. If the HDD will be installed for a –17, -29, –57 model, attach the HDD caution
decal [B] to the front cover.
7. Connect the copier and turn the machine on.
8. Go into the SP mode and do SP2801 (Developer Initialization).
9. Do some test copies to make sure that the machine operates correctly.
B205I910.WMF
[B]
