SERVICE PROGRAM MODE

SP6XXX: Peripherals

6006* DF Adjustment
These settings adjust the registration and other settings for the ADF mode. Use
the
see "Replacement and Adjustment - Copy Adjustment" for details.
6006 1 Side-to-Side
(For Simplex)
6006 2 Leading Edge
6006 3 Trailing Edge Erase
6006 4 Side-to-Side/Rear
(For Duplex)
6006 5 Sub Scan
Magnification
6006 6 Skew Correction
6006 7 Original Buckle Adj
6007 ADF Input Check
Displays the signals received from sensors and switches of the ARDF.(
6008 ADF Output Check
Switches on each electrical component (ARDF motor, solenoid, etc.) of the ARDF
for testing. ( 5.1.6)
Press
6009 ADF Free Run
Performs an ARDF free run in duplex mode. Press
1: To Start, 0: To cancel
This is a general free run controlled from the copier. For more detailed free run
modes, see the ARDF manual.
6010* Stamp Position Adjustment
Adjusts the stamp position in the sub-scan direction in fax mode.
[–5.0 ~ +5.0 / 0 / 1 mm/step]
6016* ADF Original Size Detection
Selects whether the machine determines that the original is A4/LT, or 8K/16K
when the APS sensor in the ADF does not detect the original size.
8K/16K is not available for 115V machines.
[0 = Normal (LT for USA models, A4 for Europe/Asia models)
1 = Reversed [A4 for USA models, LT for Europe/Asia models]
2 = 8K/16K]
key to toggle between + and - before entering a value. For more details,
[–5.0 ~ +5.0 / 0.0 / 0.1 mm/step]
Adjusts the trailing edge erase margin.
[–5.0 ~ +5.0 / 1.0 / 0.1 mm/step]
Adjusts the side-to-side registration on the rear side of
the original.
[–5.0 ~ +5.0 / 0.0 / 0.1 mm/step]
Adjusts the sub scan magnification.
[–5.0 ~ +5.0 / 0.0 / 0.1 % step]
Selects whether skew correction is done.
0 = Off, 1 = On
Adjusts the amount of original buckle at the ARDF
registration roller when the ARDF feeds the back side of
the original.
[–5.0 ~ +5.0 / 0.0 / 0.1 mm/step]
to switch on or to switch off.
5-74
21 July 2006
5.1.5)
to start.
