COPIER INSTALLATION

1.2 COPIER INSTALLATION

1.2.1 POWER SOCKETS FOR PERIPHERALS

CAUTION
Rating voltage for peripherals.
Make sure to plug the cables into the correct sockets.
1. Rating voltage output connector
for accessory Max. DC24 V
3. Duplex Unit
1. Rating voltage output connector
for accessory Max. DC24 V
1. ADF 2. Bridge Unit or Shift Tray
1. Rating voltage output connector
for accessory Max. DC24 V
4. By-pass Tray
1. Rating voltage output connector
for accessory Max. DC24 V
1-4
21 July 2006
B205I107.WMF
