Ricoh R-C4 Service Manual page 38

21 July 2006
[F]
[E]
[D]
[B]
B386I107.WMF
2. Remove the left scale [A] (
3. Peel off the backing [B] of the double-sided tape attached to the glass holder.
4. Place the DF exposure glass [C] on the glass holder.
NOTE: When installing the DF exposure glass, make sure that the white point
[D] is on the lower front side of the glass, as shown.
5. Peel off the backing [E] of the double-sided tape attached to the rear side of the
scale guide [F], then install it (
6. Install the two stud screws [G].
7. Mount the DF on the copier, then slide the DF to the front as shown.
8. Secure the DF unit with two screws [H].
9. Connect the cable [I] to the copier.
INSTALLATION REQUIREMENTS
[C]
[G]
[A]
[G]
[H]
x 2).
x 2 removed in step 2).
1-25
[H]
[I]
B386I104.WMF
