Appendix C: Pin Definition for Multiport Cable
GPIO Connector
Connector location: P3
5
9
P1 Pin
P3 Pin
Definition
2
1
GPI_0
12
2
GPI_1
8
3
GPI_2
3
4
GPI_3
13
5
GPO_0
9
6
GPO_1
4
7
GPO_2
14
8
GPO_3
10
9
IOC_GND
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
1
6
CAN1 Connector
Connector location: P4
5
9
P1 Pin
P4 Pin
10
2
5
3
MCU_CAN1_H
15
5
MCU_CAN1_L
59
1
6
Definition
IOC_GND
