Chapter 3: Jumpers and Connectors

ultraONE+ Internal IO Connector

Connector type: 2x25 50-pin header
Connector location: JP7
2
1
Pin Definition
1 GND
3 EDP_TX1P
5 EDP_TX1N
7 GND
9 EDP_TX0P
11 EDP_TX0N
13 GND
15 EDP_AUX_P
17 EDP_AUX_N
19 GND
21 SMB_CLK
23 SMB_DATA
25 DPC1_HPD
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
2 GND
4 USBHUB_4P_C
6 USBHUB_4N_C
8 GND
10 NC
12 NC
14 GND
16 USBHUB_3P_C
18 USBHUB_3N_C
20 GND
22 NC
24 GND
26 GND
50
49
Pin Definition
27 IO_HW_PWRBT
29 BKLTCL_CH7511
31 RST_CH7511
33 DPC1_VDEN
35 DPC1_BKLTEN
37 GND
39 LAN_MONITOR_DET
41 CH7511_GPIO1
43 CH7511_GPIO0
45 GND
47 12VSB
49 12VSB
28
Pin Definition
28 NC
30 NC
32 NC
34 NC
36 NC
38 LVDS_DET#
40 CH7511_GPIO3
42 CH7511_GPIO2
44 GND
46 VCC3
48 VCC5
50 GND
