Preface

Package Contents

Before continuing, verify that the package that you received is complete. Your package should have all the items listed in the following table.
Item P/N
1 6012200053X00
2 50333P0027X00
3 50333P0028X00
4 602DCD1538X00
5 603POW0234X00
6 50311F0100X00
7 603ANT0115X00
8 4NCPM00302X00
9 60111A0477X00
10 60111A0478X00
11 6013301009X00
12 6012200119X00
13 5061100212X00
14 6030000286X00
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Name
PE Zipper Bag #3
Washer for SMA CONN
Washer for SMA CONN
VTC 1011 Series DVD Driver VER:1.0
Power Cable 8-pin to 6-pin 12V DC OUT
Round Head Screw w/Spring+Flat Washer
Long Fei:P3x6L
GPS/GLONASS Antenna
Terminal Blocks 3P Phoenix Contact:1777992
Inner Carton for VTC 1011
Outside Carton for VTC 1011
EPE for VTC 1011
PE Bag for SECUI MF2-50
Wi-Fi Module Sponge for VTC 1011
Multi Cable for VTC 1011
Specification
100x70mm, w/China RoHS Symbol
13x1.8mm Nylon 66 Natural
12.8x6.4x0.8mm PC Black
JCL
ATX 2x4 PIT:3.0mm to ATX 2x3 PIT:4.2mm UL1007
22AWG L=200mm
P3x6 iso/SW6x0.5 NI
SMA Male L=5000mm
5.08mm MALE DIP Green
267x224x171mm B Flute
470x282x370mm AB Flute
260x160x74mm
PE Bag 330x320x0.08mm
32.3x15mm 1.8T EPDM E4308 1.5T+3M9888T Black
DB15 to DB9Fx2/DB9Mx1 L=300mm
xiv
Qty
1
6
6
1
1
4
1
1
1
1
2
1
1
1
