Appendix H: Power Consumption

a h: P
PPendIx
OS: Windows 7
Burn-in Software: Version 6.0
Device:
Idle: Into OS + VGA/HDMI/ultraONE+ display + Keyboard & Mouse +
Speaker + mSATA
Full State: Run BURN-IN + VGA/HDMI/ultraONE+ display + Keyboard &
Mouse + Speaker (Sound volume max) + 3G LINK (player Video) + mSATA
(transfer) + COM loopback + GPIO LED x5
Full State + Loading: Full state + DC-out loading + USB loading +
COM_PWR loading + PoE loading
Copyright © 2018 NEXCOM International Co., Ltd. All Rights Reserved.
C
ower onsumPtIon
Device Test Case
Idle State
S0 State Full State
Full State + Loading
(PoE load x 2)
70
Result
Current(A) Watt(W)
12V 1.86 22.32
24V 1.07 25.68
36V 0.78 28.08
12V 2.27 27.24
24V 1.21 29.04
36V 0.88 31.68
12V 11.77 141.24
24V 5.09 122.16
36V 3.42 123.12
