Chapter 1: Product Introduction
Connector Numbering
The following diagrams indicate the numbers of the connectors. Use these
numbers to locate the connectors' respective pinout assignments on chapter
2 of the manual.
VTC 1011-C2K Front View
1
2
3
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
4
8
6
5
7
9
VTC 1011-C2K Rear View
11
12
8
13
14
15
16
17
VTC 1011 Series User Manual
