Chapter 3: Jumpers and Connectors
RTC Battery Connector
Connector type: 1x2 2-pin header
Connector location: J7
1
2
Pin
Definition
1
GND
2
RTC_BAT
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
COM2 RI/Power Select
Connector type: 2x3 6-pin header
Connector location: JP9
2
6
1
5
Pin
Definition
3 ~ 4 Short
Support UART RI
1 ~ 3 Short
Support +5V
3 ~ 5 Short
Support +12V
29
VTC 1011 Series User Manual
