Chapter 3: Jumpers and Connectors
V2X Power Connector
Connector size: 1 x 2 = 2-pin header
Connector location: J19
2
1
Pin
Definition
1
5VDC
2
GND
Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved.
DC Out Connector
Connector size: 2 x 4 = 8-pin header
Connector location: CN7
8
5
4
1
Pin
Definition
1
12VDC
3
EXT_RX
5
GND
7
PUSH_BT_SLEEPIN
27
Pin
Definition
2
PUSH_BTN_PWRIN
4
EXT_TX
6
GND
8
PUSH_BTN_RSTIN
VTC 7252-7C4IP User Manual
