Chapter 4: System Setup

3. Connect the SATA cables and power cables. Then reinstall the storage

bracket onto the mainboard using the screws removed earlier.

Installing a WWAN Module (M.2)

For LTE Module, 3042:

1. Locate the WWAN M.2 slot (CN5). Insert the module into the M.2 slot at

a 45 degrees angle until the gold-plated connector on the edge of the

module completely disappears inside the slot. Then fasten a screw into

the mounting hole to secure the module.
