WLAN and mSATA Setting

Selecting the application type of the CN3 signal
For Wi-Fi or mini-PCIe module, please select PCIe (PCIe + USB 2.0).
For mSATA module, please select SATA.
Aptio Setup Utility - Copyright (C) 2021 American Megatrends, Inc.
Advanced
Onboard Module Setting
WWAN1 Module
WAN1 Wake Up
Wake On LAN
iAMT Low Power Wake Up
POE Power
RTC Alarm Time
Reboot when Ignition is On
CN18 Type
INT settings in CAN Bus Module
CAN Bus IRQ
INT settings in CAN2 Bus Module
CAN2 Bus IRQ
Version 2.20.1275. Copyright (C) 2021 American Megatrends, Inc.
Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved.
Select Connector Type.
[Enabled]
[Enabled]
[Disabled]
[Disabled]
[Enabled]
[Disabled]
[Disabled]
[SATA]
CN18 Type
PCIe
SATA
→←: Select Screen
↑↓: Select Item
12
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Selecting the application type of the CN4 signal
For Wi-Fi or mini-PCIe module, please select PCIe (PCIe + USB 2.0).
For mSATA module, please select SATA.
Aptio Setup Utility - Copyright (C) 2021 American Megatrends, Inc.
Advanced
Onboard Module Setting
WWAN1 Module
WAN1 Wake Up
Wake On LAN
iAMT Low Power Wake Up
POE Power
RTC Alarm Time
Reboot when Ignition is On
CN18 Type
INT settings in CAN Bus Module
CAN Bus IRQ
INT settings in CAN2 Bus Module
CAN Bus IRQ
Version 2.20.1275. Copyright (C) 2021 American Megatrends, Inc.
74
Select Connector Type.
[Enabled]
[Enabled]
[Disabled]
[Disabled]
[Enabled]
[Disabled]
[Disabled]
[SATA]
[Enabled]
12
[Enabled]
→←: Select Screen
11
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
VTC 7252-7C4IP User Manual
