Chapter 2: External Connectors Pinout Description

C 2: e
haPter xternal

Reset Button

Connector number: 1
1 2
Pin Definition
1 GND
2 RST_BTN#
Copyright © 2021 NEXCOM International Co., Ltd. All Rights Reserved.
C P
onneCtors

LED Indicators

Connector number: 2
STORAGE
5
d
Inout esCrIPtIon
LED4 LED3
POWER WWAN ACT1
WLAN ACT2
P1 LAN1 ACT3
P2 LAN2 ACT4
LED4 LED3
Power WWAN
Storage WLAN
Program 1 LAN1
Program 2 LAN2
LED2 LED1
PoE1
PoE2
PoE3
PoE4
LED2 LED1
PoE ACT1 PoE PWR1
PoE ACT2 PoE PWR2
PoE ACT3 PoE PWR3
PoE ACT4 PoE PWR4
