86 Specifications
LAN Interface:
DTE side ............................................. Ethernet IEEE-802.3 standard
Digital Cable Signal ............................ 10/100 Base-T
LAN cord, 4 Twisted Pair ................... supplied with the phone
LAN Cable requirements:
Power Type-A ..................................... 4 Twisted Pair
Power Type-B...................................... 2 Twisted Pair
Power Type-C...................................... 2 Twisted Pair
PC Interface:
DCE side ............................................. Ethernet IEEE-802.3 standard
Digital Cable Signal ............................ 10/100 Base-T
LAN/PC ports:
Power Requirements (Including Backlight and TEM):
Supplying Power to the Phone, page
(see
Type-A/B ............................................. 5.0W Max. Power over Ethernet (PoE)
Type-C ................................................. AC Wall Power Adapter (see below)
Power Source Option:
T207M, T208M, T208M/BL............... PoE, Adapter
T207M/NP........................................... Adapter only
AC Wall Power Adapter:
The ONLY power adapter that is to be used is one of the above three units.
The use of any other power supply will void the warranty.
Cord Cat#: 7244-0904110 can also be
used
UTP Category-5
Integrated 2-port Ethernet switch
IEEE 802.3 10BaseT / 802.3u 100BaseTx compliant,
Auto-negotiation with link speed and full/half duplex mode,
Auto MDI/MDIX for both downlink and uplink auto-swapping,
Supports QoS IEEE 802.1p voice priority function,
IEEE 802.1q VLAN function
37)
(IEEE-802.3af Standard)
Not Supplied With Phone
Input:
110-240VAC, 50/60Hz
Output: 2000mA Max. @ 5VDC
Cat#: TPS200US:77440952800
Cat#: TPS200EU:77440952900
Cat#: TPS200UK:77440953000
