Line Distances
The T207/T208 is designed to operate over Ethernet LAN with a connection of up to
100 meters to the local switch when using Category 5 UTP (unshielded twisted pair).
See Figure 13 below for an illustration of the placement of IP stations in relation to
their LAN hubs.
Figure 13 Line Distances
Ethernet Switch
Aeonix
PC
100 meters
Switch
Switch
PC
100 meters
Switch 10/100
100 meter
Switch
100 meters
PC
T207 / T208 T207 / T208
