Parameter
IP Type
IP Address
Subnet Mask Use this field to enter a Static
Internet
Connection
Items
Default
Gateway
Domain
Name
Primary DNS Use this field to enter a static
Option
Network
Items
VLAN Mode
Vlan Items
Voice VLAN
ID
Description
Select Static or DHCP to define the
mode of IP address definition for the
phone.
This field is automatically updated
from the phone.
Use this field to enter a Static IP
Address for the phone.
When a DHCP server is used, this
field is irrelevant and displays the IP
Address loaded into the phone's
Config>Network>Network
Type>Static IP field.
Subnet Mask Address for the
phone.
When a DHCP server is used, this
field is irrelevant and displays the IP
Address loaded into the phone's
Config>Network>Netmask field.
Use this field to enter a static
Default Gateway IP Address for the
phone.
When a DHCP server is used, this
field is irrelevant and displays the IP
Address loaded into the phone's
Config>Network>Default Gateway
field.
The domain name of the
organization.
Primary DNS for the phone.
When a DHCP server is used, this
field is irrelevant and displays the IP
Address DNS loaded into the
phone's Config
>Network>DNS>Primary DNS field.
Define the VLAN mode.
None: Enter None when no VLANs
are defined for your system.
Dynamic: Enter Automatic to
enable the system to automatically
configure the VLAN ID as required
for your system.
Static: Enter Static to define a
specific Voice VLAN ID.
Enter the VLAN Option ID only
when Static is defined for the VLAN
mode.
You must obtain this number from
your system administrator.
Configuring the Phone via its Web Page
Phone
SysDef > IP Parameters >
Network Type > Static
IP/DHCP
SysDef > IP Parameters >
Network Type > Static IP
SysDef > IP Parameters >
Netmask
SysDef > IP Parameters >
Default Gateway
SysDef > IP Parameters >
Domain Name
SysDef > IP Parameters >
DNS > Primary DNS
SysDef > IP Parameters >
Vlan Mode
SysDef > IP Parameters >
Voice Vlan ID
61
