EX4200 Management Cable Specifications and Pinouts

IN THIS SECTION

Management Cable Specifications | 78

Console Port Connector Pinout Information | 79
USB Port Specifications for an EX Series Switch | 79
RJ-45 Management Port Connector Pinout Information | 80
RJ-45 Port, SFP Port, SFP+ Port, QSFP+ Port, and QSFP28 Port Connector Pinout Information | 81
RJ-45 to DB-9 Serial Port Adapter Pinout Information | 85
Uplink Modules Connector Pinout Information for EX4200 Switches | 86
Virtual Chassis Ports Connector Pinout Information for EX4200 Switches | 95
Management Cable Specifications
Table 23 on page 78 lists the specifications for the cables that connect the console and management ports
to management devices.
Table 23: Specifications of Cables to Connect to Management Devices
Ports
RJ-45 Console port
Management Ethernet port
Mini-USB Type-B Console
port
Cable Specifications
CAT5e UTP (unshielded
twisted pair) cable
Ethernet cable with an
RJ-45 connector
Mini-USB cable with
standard-A and Mini-USB
Type-B (5-pin) connector
Receptacle
RJ-45
RJ-45
Mini-USB
Additional Information
"Connect a Device to a
Management Console Using
an RJ-45 Connector" on
page 142
"Connect a Device to a
Network for Out-of-Band
Management" on page 141
