Components

7.1.1 Components
Unique Fit Adapters
Array
Ultrasound
Navigation
Adapter Array
(22595)
Before You Begin
Warning
Before performing navigation, the ultrasound probe must be calibrated using the
Ultrasound Registration Phantom.
Warning
Any movement of the probe independent from the adapter will cause inaccuracy during
navigation, endangering the patient.
Before attaching an adapter to the ultrasound probe, make sure you select the correct
adapter for your probe.
Ultrasound adapters are designed for specific ultrasound probes. If it is difficult to attach
the adapter on the probe check if it is damaged or the correct type. Avoid using heavy
force when attaching the adapter as it could damage the ultrasound probe.
Additional Ultrasound Adapters
Ultrasound Adapter
41860-10A
41860-11
41860-12
41860-15
41860-1A
41860-2
41860-20
41860-21
41860-24
41860-25
41860-27A
86
Transducer/ Adapters
Probe
Ultrasound Navigation
Adapter Base
BK Medical
• BK 8862/8863/N11C5S
• BK N13C5
Ultrasound Clamp for UST
5268P-5/52114P (Aloka)
• Adapter Base for UST
Aloka
987/9104/9120 (Aloka)
• Ultrasound Integration
Adapter Base (Aloka
UST-9133)
Product Name
Ultrasound Clamp Aloka UST 995-7.5
Ultrasound Clamp Hitachi EUPF 331
Ultrasound Clamp Siemens P8-3 & 7,5 PL13 Rev.02
Ultrasound Clamp V7 (Acuson)
Ultrasound Clamp For UST 5268P-5 / 52114P (Aloka)
Ultrasound Clamp B&K 8562
Ultrasound Clamp Siemens 5.0/7.5 Microsector
Ultrasound Clamp GE 10S Sectortransducer
Ultrasound Adapter Siemens Sonoline C8-5
Ultrasound Adapter VF13.5SP Siemens
Ultrasound Adapter Toshiba PSF65AT
Fit
Unique
(recalibration
not required)
Standard
Unique
(recalibration
not required)
Instrument User Guide Rev. 2.3 Cranial/ENT Optical
Article No.
• 41860-35B
• 41860-40
41860-1
• 41860-5
• 41860-36
