POINTERS
4.3

Softouch Pointer

Introduction
The Softouch Pointer (18390) maps the patient position to the patient's diagnostic image data. It
is a precalibrated pointer used to register landmarks or CT/MR markers worn by the patient.
Compatible Batteries
Type
FR03, LiFeS
LR03, Alkaline/1.5 V/size AAA
NOTE: Do not use rechargeable batteries. It is recommended to use lithium/iron disulfide
batteries. The Softouch Pointer may also work with alkaline batteries, but with a reduced lifetime.
Components
No. Component
③
②
①
NOTE: The Softouch Pointer turns off automatically after two minutes.
Instrument User Guide Rev. 2.3 Cranial/ENT Optical
/1.5 V/size AAA
2
Func-
tion
Status LED Pointer
(visible) status
Infrared LED
Allows camera to track the pointer
(not visible)
Switches device on/off, and places it in standby mode.
Standby
• Turn on: press the switch for less than one second
switch
• Turn off: press the switch for two seconds
Description
Lithium/iron disulfide battery
Recommended: ENERGIZER Ultimate Lithium (1200mAh)
Alkaline battery
①
Figure 15
Status Color
Functioning
Green
properly
Orange Continuous
Not functioning
properly
Red
②③
Description
Ready to acquire
Continuous
points
1x short flash Acquired a point
2x long flash Turning on
4x long flash Turning off
Battery low
Continuous Battery empty
15x flashing Error is detected
