INSTRUMENT ADAPTERS
6.2
Instrument Adapter Clamps for Rectangular/
Cylindrical Instruments
Introduction
Two instrument adapter clamps are available for use with cylindrical or rectangular instruments.
Instrument Adapter Clamps
No.
How to Attach the Clamp
Step
1.
2.
3.
Instrument User Guide Rev. 2.3 Cranial/ENT Optical
①
Product
①
Instrument Adapter Clamp for Blakesley/Rectangular Instruments
②
Instrument Adapter Clamp for Cylindrical Instruments
①
For rectangular instruments, attach the adapter ① to the rear handle of the forceps.
For cylindrical instruments, insert the cylindrical instrument into the adapter ②.
Make sure that the clamp notch matches the instrument handle.
Attach the relevant Instrument Adapter Array to the adapter.
②
Figure 41
Figure 42
Article No.
55105
55110
②
83
