Suction Tubes

Introduction
Brainlab suction tubes (55790, 55790-XX) are available in different sizes and with two different
tips.
Specifications
No.
①
②
③
Calibration
Always recalibrate the tip after every adapter exchange.
Instrument User Guide Rev. 2.3 Cranial/ENT Optical
①
Suction Angle
Tube
Double-angled:
Frontal • 120° (near han-
Sinus dle)
• 110° (tip)
Maxillary
110°
Sinus
Standard 135°
②
Figure 9
Available Tips Article No.
Size Type Right-Handed
Pear tip 55790-25
8
Frazier tip 55790-20
Pear tip 55790-40
10
Frazier tip 55790-45
Pear tip 55790-50
8
Frazier tip 55790-55
Pear tip 55790-60
10
Frazier tip 55790-65
Pear tip 55790-05
8
Frazier tip 55790-75
Pear tip 55790
10
Frazier tip 55790-70
③
Left-Handed
55790-10
55790-15
55790-30
55790-35
N/A
