POINTERS
4.2

Multiple Tip Pointer Package

General Information
The Multiple Tip Pointer Package (B12201) is available with interchangeable tip geometries,
supporting a wide range of surgical approaches.
Components
Name
Paint Pointer Tips
The paint pointer tips are designed for accessing sinus cavities and are available for use in
combination with Paint software features.
NOTE: Only use the paint pointer tips with the Handle for Multiple Tip Pointer.
No. Component
①
②
Instrument User Guide Rev. 2.3 Cranial/ENT Optical
Tip Length
95 mm
100 mm
60 mm
Pointer Tip
115 mm
123 mm (3.4 diameter)
150 mm
Handle for Multiple Tip Pointer
①
Eraser Pointer Tip (Curved)
Tip Set for Paint Pointer
Figure 12
Curved Tip End Length Offset
20 mm (-70° angle)
20 mm (-90° angle)
N/A
Figure 13
Length
130 mm
Article No.
30° 55791-03
55791-04
0°
55791-05
45° 55791-02
55791-34
0°
55791-01
55791
②
Article No.
55791-06
41783
