GENERAL INSTRUMENTATION
Part
Registration sockets (with funnel-shaped indents for exact
localization of the detected marker center)
NOTE: Store the kit within easy reach in the OR.
Multi-Modality Donut Registration Markers (52160)
Multi-Modality Donut Registration Markers are used as an artificial fiduciary marker on a
patient's skin to facilitate localizing and documenting the precise superimposition of imaging data
from CT, MRI, and other imaging sources.
Correct Handling
Warning
Multi-Modality Donut Registration Markers are disposable and must be disposed of after
use.
NOTE: Do not use Multi-Modality Donut Registration Markers that are visibly damaged.
Instrument User Guide Rev. 2.3 Cranial/ENT Optical
Quantity
150 each
Figure 5
