Softouch Pointer Technical Information
Electrical Specifications
Specification
Power Supply
Power Consumption max. 120 mW
Materials
Component
Housing
Tip
Isolator
Environmental Specifications
Specification
Temperature
Humidity
Pressure
Optical Specifications
Specification
Infrared LED
Visible status LED
Certifications and Classifications
Certification
IEC 60601-1
Classifications
Internally Powered ME Equipment for Continuous Operations
IP44
Exempt group: LEDs do not pose any photobiological hazards
44
Description
1.5 V, size AAA, exchangeable Lithium/iron disulfide FR03 (recommend-
ed) or alkaline LR03
Material
PC (Polycarbonate) / ABS (Acrylnitril-Butadien-Styrol-Copolymer) blend
Medical stainless steel
PEEK (Polyetheretherketone)
Transport/Storage Conditions
-10 °C to 50 °C (14 °F to 122 °F)
10% to 90% noncondensing
500 hPa to 1060 hPa
Color Description
Wavelength: λ = 870 nm (IR-A)
N/A
Wavelength: λ = 570 nm
Green
Wavelength: λ = 630 nm
Red
Operating Conditions
10°C to 35°C (50°F to 95°F)
20% to 80% noncondensing
700 hPa to 1060 hPa
According to
IEC 60601-1
IEC 60529
