9F-9 Security and Locks:
For rear end door
c a
b
d
Terminals
Lock
Unlock
Terminals c
Lock
Unlock

Rear Door Lock Assembly Components

1. Outside handle
: Apply lithium grease 99000-25011 to sliding part.
2. Outside handle frame
: Apply lithium grease 99000-25011 to sliding part and spring.
3. Rear door latch assembly
: Apply lithium grease 99000-25011 to sliding part.
a b
Unlock
Lock
d
I5JB0A960011-02
1
(a)
6
7
2
(a)
3
4. Latch striker
5. Shim
6. Inside handle bezel
S6JB0A9606007
(a)
4
5
(b)
I5JB0A960012-03
7. Out side handle cap
: 5.0 N⋅m (0.5 kgf-m, 4.0 lb-ft)
: 10 N⋅m (1.0 kgf-m, 7.5 lb-ft)
