Suzuki Grand Vitara 2011 Manual page 2215

1
2
10
11
12
[A]: Driver side door outside handle
[B]: Passenger side or rear end door outside handle
[C]: 5 door model
[D]: 3 door model
1. Keyless start control module
2. Remote controller
3. Request switch
9
14
10. Unlock button
[C]
13
4
4. Center antenna
5. Luggage room antenna
6. Driver side door antenna
7. Passenger side door antenna
8. Rear end door antenna
9. Steering lock unit
Keyless Start System:
[D]
15
16
[A]
3
6
[B]
7, 8
I6JB0AA50002-01
11. Lock button
12. BCM
13. Key indicator light
14. ECM
15. Luggage room antenna (LH)
16. Luggage room antenna (RH)
