A r r o w A u t o C AT
2 S e r i e s
®
I n t r a - A o r t i c B a l l o o n P u m p ( I A B P ) S y s t e m
O p e r a t i n g M a n u a l
Arrow International
9 Plymouth Street
Everett, Massachusetts 02149
(617) 389-6400 • (800) 343-3297
(617) 387-2157 FAX
24 hr. Intra-Aortic Balloon Product Hotline
(800) 447-IABP (4227) US/Canada • (617) 389-8628 Worldwide
Caution: Federal Law (U.S.A.) restricts the sale, distribution or use of this
device to, by or on the lawful order of a health professional.
Part Number: IAM-9007, Rev 0
