A-3 Test Records for Options Verification
MS272__C Firmware Rev: ______________ Operator: ____________________
Serial Number: _______________

Option 41, GSM/GPRS/EDGE Demodulator

Table A-73. Option 41, At 850 MHz, –10 dBm Level, TCH Pattern (GSM)
Measurement
Phase Err RMS (Deg)
Table A-74. Option 41, At 850 MHz, –50 dBm Level, TCH ALL Pattern (GSM)
Measurement
Phase Err RMS (Deg)
Table A-75. Option 41, At 1800 MHz, –10 dBm Level, TCH ALL Pattern (GSM)
Measurement
Phase Err RMS (Deg)
Table A-76. Option 41, At 1800 MHz, –50 dBm Level, TCH Pattern (GSM)
Measurement
Phase Err RMS (Deg)
Table A-77. Option 41, At 1800 MHz, –50 dBm Level, DL_MCS-9_1SLOT Pattern (EDGE)
Measurement
Phase Err RMS (Deg)
Table A-78. Option 41, At 1800 MHz, –10 dBm Level, DL_MCS-9_4SLOT Pattern (EDGE)
Measurement
Phase Err RMS (Deg)
A-38
Options: __________________________________________________
Measured Value
Measured Value
Measured Value
Measured Value
Measured Value
Measured Value
PN: 10580-00279 Rev. E
Appendix A — Test Records
Date: ____________
Specification
Deg
Specification
Deg
Specification
Deg
Specification
Deg
Specification
Deg
Specification
Deg
MS272xC MM
≤ 1 Deg
≤ 1 Deg
≤ 1 Deg
≤ 1 Deg
≤ 1 Deg
≤ 1 Deg
