Chapter 1 — General Information
1-1

Introduction

This manual provides maintenance instructions for Anritsu Spectrum Master Models MS2722C, MS2723C,
MS2724C, MS2725C, and MS2726C. It provides a list of recommended test equipment, performance
verification procedures, parts replacement procedures, replaceable parts list, and test records.
Familiarity with the basic operation of the front panel keys is assumed (for example, how to change
measurement mode, how to preset the instrument, or the meaning of "submenu key"). Before making any
measurement, ensure that all equipment has warmed up for at least 30 minutes.
The manual includes:
• General information in this chapter, including:
• Lists of necessary test equipment to perform verification testing
(Table 1-1,
• Replaceable parts list
• Performance verification procedures:
• Chapter 2, "Spectrum Analyzer Verification"
• Chapter 3, "Options Verification "
• Battery pack information
• Parts replacement procedures
• Troubleshooting problems
• Blank test records are included in
• Copy the blank test records from
records form a record of the performance of your instrument. Anritsu recommends that you make a
copy of the blank test records to document the measurements each time a Performance
Verification is performed. Continuing to document this process each time it is performed provides
a detailed history of instrument performance, which can allow you to observe trends.
Caution Before making any measurement, verify that all equipment has warmed up for at least 30 minutes.
