Anritsu Spectrum Master MS2722C Maintenance Manual page 157

A-3 Test Records for Options Verification
MS272__C Firmware Rev: ______________ Operator: ____________________
Serial Number: _______________
Option 44 and/or 45 and/or 65 WCDMA and HSDPA RF Measurements (Continued)
Table A-96. Option 44, HSDPA ACLR Accuracy
Frequency/Offset
2680.5 / –10 MHz
2680.5 / –5 MHz
2680.5 / 5 MHz
2680.5 / 10 MHz
Table A-97. Option 45 or Option 65, WCDMA Error Vector Magnitude (Test Model 4)
Frequency
1962.5 MHz
Table A-98. Option 65, HSDPA Error Vector Magnitude (Test Model 5)
Frequency
1962.5 MHz
A-44
Options: __________________________________________________
Measured ACLR
EVM
EVM
PN: 10580-00279 Rev. E
Appendix A — Test Records
Calculated ACLR Error
%
%
Date: ____________
Specification
± 1.0 dB
± 1.0 dB
± 1.0 dB
± 1.0 dB
Specification
± 2.5%
Specification
± 2.5%
MS272xC MM
