A-2 Test Records for Spectrum Analyzer Verification
MS272__C Firmware Rev: ______________ Operator: ____________________
Serial Number: _______________
Table A-11. Characterization Chart for Fixed Level with Varying Frequency (1 of 2)
–2 dBm (MS2722C, MS2723C, MS2724C)
Frequency
10.1 MHz
100 MHz
500 MHz
1000 MHz
2000 MHz
3000 MHz
4000 MHz
5000 MHz
6000 MHz
7000 MHz
8000 MHz
8999.995 MHz
9000 MHz
10000 MHz
11000 MHz
12000 MHz
12999.995 MHz
13000 MHz
14000 MHz
15000 MHz
16000 MHz
17000 MHz
18000 MHz
19000 MHz
20000 MHz
21000 MHz
22000 MHz
A-6
Options: __________________________________________________
–5 dBm (MS2725C, MS2726C)
PN: 10580-00279 Rev. E
Appendix A — Test Records
