Appendix A — Test Records
MS272__C Firmware Rev: ______________ Operator: ____________________
Serial Number: _______________

Option 62, EVDO RF Measurements

Table A-104. Option 62, At 870.03 MHz, –50 dBm Level, 921.6 kps 8PSK Modulation
Measurement
Power Meter Reading
MS272xC Reading
Calculated Channel Power Error
Table A-105. Option 62, At 1930.05 MHz, 0 dBm Level, 38.4 kps QPSK Modulation
Measurement
Power Meter Reading
MS272xC Reading
Calculated Channel Power Error
Table A-106. Option 62, At 1930.05 MHz, –50 dBm Level, 2457.6 kps 16QAM Modulation
Measurement
Power Meter Reading
MS272xC Reading
Calculated Channel Power Error
Table A-107. Option 62, At 1930.05 MHz, –50 dBm Level, Idle Slot
Measurement
Power Meter Reading
MS272xC Reading
Calculated Channel Power Error
MS272xC MM
Options: __________________________________________________
Measured Value
Measured Value
Measured Value
Measured Value
PN: 10580-00279 Rev. E
A-3 Test Records for Options Verification
Date: ____________
dBm
dBm
dB
dBm
dBm
dB
dBm
dBm
dB
dBm
dBm
dB
Specification
–50 dBm ± 0.2 dB
± 1.5 dB
Specification
0 dBm ± 0.2 dB
± 1.5 dB
Specification
–50 dBm ± 0.2 dB
± 1.5 dB
Specification
–50 dBm ± 0.2 dB
± 1.5 dB
A-47
