A-2 Test Records for Spectrum Analyzer Verification
MS272__C Firmware Rev: ______________ Operator: ____________________
Serial Number: _______________
Table A-61. Spectrum Analyzer DANL (Preamp On)
Frequency
Start / Stop
10 MHz to 4.0 GHz
4.0 GHz to 9.0 GHz
9.0 GHz to 13 GHz
13 GHz to 20 GHz
20 GHz to 32 GHz
32 GHz to 40 GHz
Table A-62. Spectrum Analyzer DANL (Preamp Off)
Frequency
Start / Stop
10 MHz to 4.0 GHz
4.0 GHz to 9.0 GHz
9.0 GHz to 13 GHz
13 GHz to 20 GHz
20 GHz to 32 GHz
32 GHz to 40 GHz
Table A-63. Spectrum Analyzer Third Order Intercept
Third Order Intercept at
Center Frequency
Calculated TOI at 2400 MHz
A-34
Options: __________________________________________________
RBW VBW
(kHz) (kHz)
100 1
100 1
100 1
100 1
100 1
100 1
RBW VBW
(kHz) (kHz)
100 1
100 1
100 1
100 1
100 1
100 1
2400.151 MHz
2399.851 MHz
PN: 10580-00279 Rev. E
Measured dBm Calculated dBm
(100 kHz RBW)
dBm
dBm
dBm
dBm
dBm
dBm
Measured dBm Calculated dBm
(100 kHz RBW)
dBm
dBm
dBm
dBm
dBm
dBm
Measured Value
Appendix A — Test Records
Date: ____________
(1 Hz RBW) Specification
≥ –160 dBm
dBm
≥ –156 dBm
dBm
≥ –152 dBm
dBm
≥ –145 dBm
dBm
≥ –154 dBm
dBm
≥ –147 dBm
dBm
(1 Hz RBW) Specification
≥ –141 dBm
dBm
≥ –134 dBm
dBm
≥ –129 dBm
dBm
≥ –123 dBm
dBm
≥ –134 dBm
dBm
≥ –127 dBm
dBm
Specification
dBm
dBm
≥ +15 dBm
