A-3 Test Records for Options Verification
MS272__C
Firmware Rev: ______________ Operator: ____________________
Serial Number: _______________
Option 552 and Option 543, TD-LTE Measurements
Table A-129. Option 552, TD-LTE Residual EVM and Frequency Accuracy
Measurement
For Units with Option 552 Installed, Pattern TDLTE-E-TM-3-3_10M
750 MHz at –12 dBm
Frequency Error
EVM (rms)
750 MHz at –30 dBm
Frequency Error
EVM (rms)
2350 MHz at –12 dBm
Frequency Error
EVM (rms)
2350 MHz at –30 dBm
Frequency Error
EVM (rms)
For Units with Option 543 Installed, Pattern TDLTE-E-TM-3-3_20M
750 MHz at –12 dBm
Frequency Error
EVM (rms)
750 MHz at –30 dBm
Frequency Error
EVM (rms)
2350 MHz at –12 dBm
Frequency Error
EVM (rms)
2350 MHz at –30 dBm
Frequency Error
EVM (rms)
A-56
Options: __________________________________________________
Measured Value
PN: 10580-00279 Rev. E
Appendix A — Test Records
Date: ____________
Specification
Hz
± 10 Hz
%
< 2.0% typical
Hz
± 10 Hz
%
< 2.0% typical
Hz
± 10 Hz
%
< 2.0% typical
Hz
± 10 Hz
%
< 2.0% typical
Hz
± 10 Hz
%
< 2.0% typical
Hz
± 10 Hz
%
< 2.0% typical
Hz
± 10 Hz
%
< 2.0% typical
Hz
± 10 Hz
%
< 2.0% typical
MS272xC MM
